Main Stage

Contacts

Measurements and machinery

Set walls maximum hight (stage) 6900 mm
Maximum storage area (set incl props & lights) 40 m²
Set elevator Sibyllegatan
Floor space elevator 3350 x 2850 mm
Height 4700 mm
Door street level 1230 x 4650 mm
Door stage level 1850 x 4700 mm
Load in Almlöfsgatan
Door stage level
Scissor lift table 7730 x 2390 mm
Scissor lift table max. load 3 ton
Width 10000 mm
Height 7500 mm
Depth 18900 mm
Width 17000 mm (15000 mm wide sets)
Height 18500 mm
Maximum set hight 6900 mm
Floor
Black pine floor, thickness 44 mm
Distributed load 400 kg/m2
Point load 40 kg/cm2
Set floor only allowed given special circumstances
Trap doors are possible under the revolving stage area.
Diameter 15000 mm
Programmable speed
Max speed 1 meter per second
Control
Waagner Biro
Flybars
Flybars total 34 + 1
Flybar per production 5 pcs
Maximum flybar width 15000 mm
Maximum load (distributed) 500 kg
Point load under suspension wire 150 kg
Maximum load between points 100kg
Fly bar profile 53 mm x 59 mm - 13 mm opening
Speed 0,001-1,8 m/s
Height from stage floor to maximum hight 18500 mm
LX/Lighting bridges 6
Forestage 1 Electrical (inner)
Depth 1400 mm
Width 11600 mm
Height - 1400 mm to + 1000 mm (from auditorium floor)
Black pine floor
Forstage 2 Electrical (outer)
Depth 1200 mm
Width 12000 mm
Height - 1400 mm to + 1000 mm (from auditorium floor)
Black pine floor
Must at all times be able to move freely and can’t obstructed.
Can be used during the performance but not programmed
Cannot be re-painted or covered with any material
Left side stage
Depth 4300 / 9100 mm
Width 10300 mm
Height floor to ceiling 7000 mm
Black vinyl floor
Right side stage
Depth 15500 mm
Width 19400 mm
Height floor to ceiling 7000 mm
Black vinyl floor
Left and right
Height 7 700 mm stage floor to balcony floor
Capacity 770
